| Device Logic Units |
49000 |
| Device Logic Cells |
49000 |
| Maximum Number of User I/Os |
176 |
| Device Number of DLLs/PLLs |
4 |
| Number of Multipliers |
132 (18x18) |
| Maximum LVDS Data Rate (Mbps) |
875 |
| Maximum MLAB Capacity (Kbit) |
303 |
| Tradename |
Cyclone |
| Number of Registers |
73920 |
| RAM Bits (Kbit) |
3080 |
| Total Number of Block RAM |
308 |
| Program Memory Type |
SRAM |
| Family Name |
Cyclone® V E |
| Process Technology |
28nm |
| Speed Grade |
7 |
| Dedicated DSP |
66 |
| Differential I/O Standards Supported |
LVPECL|LVDS |
| Single-Ended I/O Standards Supported |
LVTTL|LVCMOS |
| Ethernet MACs |
2 |
| JTAG Support (-) |
Yes |
| External Memory Interface |
DDR2 SDRAM|DDR3 SDRAM|LPDDR2 |
| Copy Protection |
No |
| Shift Registers |
Utilize Memory |
| Programmability |
Yes |
| In-System Programmability |
Yes |
| Reprogrammability Support |
Yes |
| Number of Global Clocks |
16 |
| Maximum Operating Supply Voltage (V) |
1.13 |
| I/O Voltage (V) |
1.2|1.25|1.35|1.5|1.8|2.5|3|3.3 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
100 |
| Temperature Flag |
Jun |
| Supplier Temperature Grade |
Industrial |
| Digital Control Impedance |
No |
| Minimum Operating Supply Voltage (V) |
1.07 |
| Typical Operating Supply Voltage (V) |
1.1 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
