| Type |
Small Signal Switching Diode |
| Configuration |
Single |
| Maximum DC Reverse Voltage (V) |
250 |
| Peak Reverse Repetitive Voltage (V) |
250 |
| Maximum Continuous Forward Current (A) |
0.2 |
| Maximum Power Dissipation (mW) |
200 |
| Speed |
Ultra Fast Recovery Rectifier |
| Peak Forward Voltage (V) |
1.25 |
| Peak Non-Repetitive Surge Current (A) |
20 |
| Peak Reverse Current (uA) |
0.1@200V |
| Peak Reverse Recovery Time (ns) |
50 |
| Operating Junction Temperature (°C) |
-55 to 150 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
