| Type |
Switching Diode |
| Configuration |
Single |
| Peak Reverse Repetitive Voltage (V) |
100 |
| Maximum DC Reverse Voltage (V) |
100 |
| Maximum Continuous Forward Current (A) |
0.25 |
| Maximum Power Dissipation (mW) |
400 |
| Repetitive Peak Forward Current (A) |
0.5 |
| Speed |
Ultra Fast Recovery Rectifier |
| Peak Forward Voltage (V) |
1.25@0.15A |
| Peak Non-Repetitive Surge Current (A) |
4 |
| Peak Reverse Current (uA) |
0.5@80V |
| Peak Reverse Recovery Time (ns) |
4 |
| Operating Junction Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Maximum Diode Capacitance (pF) |
1.5 |
| Minimum Operating Temperature (°C) |
-65 |
| Maximum Operating Temperature (°C) |
150 |
| Supplier Temperature Grade |
Automotive |
