| Type |
PNP |
| Configuration |
Single |
| Maximum Collector-Emitter Voltage (V) |
60 |
| Maximum Collector Base Voltage (V) |
60 |
| Maximum Emitter Base Voltage (V) |
5 |
| Maximum DC Collector Current (A) |
1.5 |
| Material |
Si |
| Maximum Power Dissipation (mW) |
1250 |
| Maximum Junction Case Thermal Resistance |
10°C/W |
| Maximum Collector Cut-Off Current (nA) |
100 |
| Maximum Collector-Emitter Saturation Voltage (V) |
0.5@0.05A@0.5A |
| Category |
Bipolar Power |
| Minimum DC Current Gain |
25@5mA@2V|25@500mA@2V|40@150mA@2V |
| Number of Elements per Chip |
1 |
| Minimum Operating Temperature (°C) |
-65 |
| Maximum Operating Temperature (°C) |
150 |
| Supplier Temperature Grade |
Industrial |
