• Selects Highest Priority Supply from Two Inputs
|
• Blocks Reverse and Cross Conduction Currents
|
• Wide Operating Voltage Range: 2.5V to 40V
|
• –42V Protection Against Reverse Connection
|
• 60V Tolerant V1, V2 Inputs
|
| • Adjustable Input Validation Time |
| • Fast Switchover Minimizes Output Voltage Droop |
| • Low 26µA Operating Current |
• ±1.5% Input Overvoltage/Undervoltage Protection
|
• Adjustable Overvoltage/Undervoltage Hysteresis
|
| • Cascadable for Additional Input Supplies |
| • 20-Lead 4mm × 4mm QFN Package |
|
